The Role of Domain Knowledge in Big Data for Predictive Maintenance

Industrial organizations are increasingly taking advantage of leading edge digital technologies to improve the effectiveness, accuracy and reliability of their enterprise maintenance systems.

Big data technologies provide opportunities to develop and deploy predictive maintenance systems, which enable the timely and accurate estimation of lifecycle parameters for assets and equipment, such as RUL (Remaining Useful Life) and EoL (End of Life).

Big data technologies provide the means to collect, store and process large amounts of data that indicate the condition of the equipment, such vibration, acoustic, ultrasonic, temperature, power consumption and oil analysis datasets, as well as data from thermal images of the equipment.

But gathering the data is only the first step. To derive useful maintenance insights from these datasets, plant operators and their maintenance solutions integrators employ data mining and machine learning processes.
‍

The Bias Challenges of Data Mining Processes

Data mining processes are usually iterative. They aim to evaluate different models in terms of their predictive power and robustness.

As part of these processes, data scientists test different machine learning and statistical methods options against their effectiveness in predicting parameters or deriving insights on the maintenance process at hand. For this process, data scientists divide the available data into two datasets: one for training and one for testing.

• The training dataset is used to train a machine learning program (i.e. algorithm) in proactively identifying situations that signal the need for maintenance, such as equipment degradation patterns.
• The test dataset is used to evaluate the performance of the algorithm based on parameters such as the classification or prediction accuracy.

Why must training dataset be different from the testing dataset? Testing an algorithm on the data used to train it would automatically give good results. Moreover, an understanding of the datasets and their structure is essential towards identifying models that could potentially provide the required predictive insights.

Data scientists are usually in charge of reviewing the datasets and proposing candidate machine learning algorithms. The latter need to be evaluated based on the available datasets.

One of the main challenges of the data mining process concerns the availability of proper datasets. For example, the identification of a failure state for a tool or machine based on sensor data requires several occurrences of the failure to be present in the datasets.

In general, tool failures are more frequent and therefore they are easier to find in relevant datasets. This is not always the case with machine failures, as plant owners or operators are not likely to have or keep historical data about failures of a given machine. Moreover, datasets can be dispersed across different systems, which makes the process of collecting them and ensuring they are suitable to be processed by a machine learning algorithm quite difficult.

Even in cases where proper data sets are available, the data mining process remains challenging, mainly in terms of associating insights found in the datasets with the real-life maintenance problems.

Specifically, all data mining processes are subject to bias problems, which stem from the fact that data scientists tend to tailor their programs to what is available in the datasets, in a way that achieves optimal performance on the test datasets.

This process, while optimal from a mathematical perspective, fails in several cases to produce effective results as it completely ignores the parameters of the business problem at hand.

For instance, the role of a specific parameter (e.g., temperature or humidity) on a degradation pattern could be short-lived or seasonal, rather than a decisive indicator that must be monitored at all times.

As another example, some failure indicators may relate to specific lots of a tool or part and should not be considered as permanent indicators of some failure mode.

Such seasonal or short-lived factors cannot be understood and excluded by a machine algorithm: As soon as they are consistently present in a dataset, the algorithm will likely consider them significant contributors to the failure.

Furthermore, these factors will be taken into account proportionally to the times they appear in the dataset, without considering their seasonality or randomness of appearance.
‍

Domain Knowledge to Your Rescue

To alleviate the overfitting bias, maintenance solution providers have to consider domain knowledge. The latter refers to knowledge and insights that are unique to the target industry and enterprise for which the solution is destined.

You must consider such knowledge during the implementation of any analytics project; Without domain knowledge, the predictive analytics solution will fail to address the real maintenance problem.

Likewise, no data-driven predictive maintenance solution can be deployed without involving experts in the maintenance solution development process.

In the maintenance practice, domain knowledge is reflected in an organization’s FMEA (Failure Mode and Effects Analysis) and FMECA (Failure Modes, Effects and Criticality Analysis methodologies, which incorporate knowledge that:

• Identifies potential failure modes for a product or process, which drives data scientists work in terms of the identification of these modes.
• Assesses the risk associated with each one of these failure modes, which enables data scientists to seek for the proper risk factors and their probabilities in the collected data.
• Ranks the issues in terms of importance, which steers the work to the most serious failure factors. Detecting and addressing the latter factors maximizes the value for money of the solution.

In practice, FMEA and FMECA processes provide expert knowledge in terms of the assets, their failure modes, the effects and causes of the various failures, as well as current controls and recommended actions.

Moreover, they include some methods for assessing risks associated with the issues that are identified during the analysis, including prioritization of corrective actions.

The latter is based on methodologies such as assigning Risk Priority Numbers (RPNs).  RPNs are assigned for each failure mode based on the severity of a failure, the likelihood of occurrence for each cause of failure, and the likelihood of the prior detection for each cause of failure. In particular, RPNs are calculated by obtaining the product of the above listed ratings (i.e. Severity, Occurrence, Detection).

In the scope of the data mining, RPNs can then be used to prioritize algorithms and alleviate overfitting. To this end, data scientists do not select the algorithms that are the optimal from the mathematical viewpoint. On the contrary, they can select algorithms that best reflect the RPNs of the highest priority, in addition to considering their statistical presence in the dataset.

As a prominent example, data scientists should focus on predictive algorithms and attributes that focus on the most critical failures that must be avoided, as they are the most expensive and time consuming to repair, while leading to loss of prominent equipment functions.

The combination of insights from the FMECA/FMEA with knowledge derived from the data sets can lead to systems that better solve today’s maintenance problems. At the same time, they lead to systems with better value for the investment, meaning they contribute to many organizations’ top maintenance goals.
‍

Taking Advantage of Domain Knowledge

To take advantage of domain knowledge in big data predictive maintenance systems, the following best practices and recommendations should be taken into account:

Assemble The Right Team‍

It is essential that you incorporate domain experts into your big data team. They should work closely with data scientists, database experts, and programmers to deliver a solution that is not only technically robust, but also optimal for the business.

Domain experts (e.g., maintenance workers and engineers) should be part of the team and engage actively throughout the project (not on an occasional basis).

Test and Learn‍

The data mining process is iterative. Each algorithm and piece of expert advice should be tested and validated prior to being deployed.

Note that this process acts as an educational device for both data scientists and domain experts too, who will only become knowledgeable about the process with each iteration. Likewise, they are likely to come up with new ideas to test and validate in the next cycle.

Invest in Domain Knowledge and Processes‍

Predictive maintenance based on digital technologies is not possible without proper FMECA/FMEA processes in place. Therefore, investments in digital technologies should also be accompanied with investments in complementary assets, such as domain knowledge and processes.

Successful Predictive Maintenance Solutions Aren’t Easily Replicated‍

It’s not easy to replicate a successful solution in different contexts (e.g. different plants and equipment). Each plant is likely to have its own unique FMECA/FMEA processes and therefore different domain knowledge and datasets.

Thus, each new big data project for predictive maintenance presents new challenges and there is only little room to exploit components from other deployments without changing and customizing them.

Communicate New Data-Driven Knowledge‍

While expert knowledge is an important driving factor of data mining, don’t forget that data processing is able to derive insights and knowledge that was not known beforehand. Therefore, there should be a two-way interaction between data scientists and domain experts during the mining process.

On the one hand, experts will provide knowledge that drives the specification of proper algorithms. On the other hand, the application of certain data processing algorithms on the maintenance datasets is likely to reveal new insights that data scientists should communicate back to the domain experts.

Collaborate‍

Big data from predictive maintenance is all about stakeholders’ collaboration. Data scientists, maintenance experts, IT experts should closely collaborate in developing the proper machine learning and data mining experts. Moreover, commitment from the C-Suite is also essential in order to lower resistance barriers and to successfully manage change.
‍

Utilize Analytics to Improve Predictive Maintenance

Overall, successful Big Data analytics for predictive maintenance requires that business goals and expert knowledge are well understood, alongside the maintenance datasets. The importance of domain knowledge is proven, not only in the case of enterprise maintenance, but also in a variety of use cases for other industrial sectors.

It’s essential that you structure such domain knowledge and that you engage relevant experts in your next enterprise maintenance big data project. We hope that the above best practices will help you make this project a success.
